Actisense
Actisense Micro female connectors, 3 metre UL certified cable, left and right power feed pairs
Description
| Electrical | |
| Rated Current | 4A (each feed) |
| Rated Voltage
|
60VDC
|
| Mechanical | |
| Female Contact | Phosphor bronze, gold plated |
| Contact Carrier | PA66 (30% Glass Filled), Black |
| Contact Polarisation | Standard M12 -“A”- polarisation |
| Mating Thread | M12 |
| Screw Cap | Brass, nickel plated |
| O-Ring Seal | Rubber, black |
| Housing | PVC, black |
| Cable Jacket Material | 0.8mm Nom. PVC, orange |
| Cable Outer Diameter | 6.7mm ±0.254mm |
| Cable Length | 3M |
| Wire Length | 100mm (7mm stripped) |
| Wire Jacket | PVC |
| Wires | 18 AWG (stripped and tinned) |
| Drain | 18 AWG (34 strand tinned copper) |
| Shield | Al-mylar |
| Weight
|
290g
|
| Approvals and Certifications | |
| NMEA 2000 Approved | |
| RoHS Compliant | |
| UL Certified Cable (E137250) | |
| Protection | IP67 (when mated) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
Tech Specs
