MPS Pump 1250 GPH 24V 115/230V 50/60 Hz
Mabru marine air conditioning raw water pumps are small, efficient, quiet and extremely reliable. Our pumps are significantly smaller than our competitors' which allows for much easier installations in con?ned bilge spaces. We utilize permanent magnet, brushless DC motors coupled with magnetic drive, non friction impellers to maximize efficiency and durability. All of our pumps are fully submersible and ignition protected.MPS Pump Datasheet
| MODEL MPS PUMP | 250 | 650 | 950 | 1250 |
| Voltage/Hz | 110/220VAC / 12/24VDC | 110/220VAC / 12/24VDC | 110/220VAC / 12/24VDC | 110/220VAC / 12/24VDC |
| Amps@24VDC | 0.75 | 1 | 1.4 | 1.5 |
| Waterproof | Yes | Yes | Yes | Yes |
| Max Head Ft. H20 | 10in | 22in | 38in | 35in |
| GPH | 250 | 650 | 950 | 1250 |
| Inlet Size (in) | 1/2 | 1/2 | 3/4 | 1 |
| Outlet Size (in) | 1/2 | 1/2 | 3/4 | 1 |
| Height (in/mm) | 1.73 in/ 44 mm | 3.74 in/ 95 mm | 5.19 in/ 132 mm | 5.51 in/ 140 mm |
| Width (in/mm) | 3.3 in /84 mm | 2.76 in/ 70 mm | 3.93 in/ 100 mm | 4.33 in/ 110 mm |
| Length (in/mm) | 3.35 in / 85 mm | 4.01 in/ 102 mm | 5.70 in/ 145 mm | 7.67 in/ 195 mm |
| Weight (lbs/kg) | 0.5 lbs/ 1.1 kg | 1.55 lbs/ 3.41 kg | 2.5 lbs/ 5.5 kg | 4.50 lbs / 9.9 kg |
